Chaoya is a professional china manufacturer in production of micro coreless geared motor with different diameter typically ranges from 10mm to 20mm, which is one of the hollow cup gear motor’s most crucial features. So It's essential to choose the correct size to ensure proper operation and efficiency of your equipment.
The following is an introduction to micro coreless geared motor with different diameter including from 10mm to 20mm, which is produced by china factory chaoya. As we known, Choosing a motor that is too small or too large can cause problems with performance and longevity, the good way to determine what size you need is by considering the torque and speed requirements of your equipment. micro coreless geared motor with different diameter boasts several advantages, the most significant advantage is high efficiency making them ideal for applications where space is limited . Another advantage is low noise, these motors operate quietly, making them ideal for use in medical equipment, toys, and robotic applications.what’s more, the high gear ratio of these motors allows them to output high torque at low speeds, making them ideal for use in robotics and automation applications. All these features make micro coreless geared motor with different diameter suitable for a wide range of applications, including robotics, medical equipment, toys, and automation applications.So Using micro coreless geared motor with different diameter can help improve performance and efficiency of your equipment while reducing noise and space requirements.
| Model：#16 | A1 | A2 | A3 | A4 | A5 |
| Maximum allowable input speed in continuous operation (rpm) | 35000 | 35000 | 35000 | 35000 | 35000 |
| Reducer length (mm） | 17.9 | 21.8 | 25.7 | 29.6 | 33.5 |
| Rated allowable load (Nm) | 0.42 | 0.6 | 0.75 | 0.9 | 0.9 |
| Peak load (Nm) | 1.26 | 1.8 | 2.25 | 2.7 | 2.7 |
| Transmission efficiency (%) | 90% | 85% | 76% | 70% | 68% |
| Gear class | 1 | 2 | 3 | 4 | 5 |
| Housing/Gear Material | Metal | Metal | Metal | Metal | Metal |
| Radial load (N) | 15.6 | 15.6 | 15.6 | 15.6 | 15.6 |
| Axial load (N) | 4.9 | 4.9 | 4.9 | 4.9 | 4.9 |
| Radial clearance (mm) | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 |
| Axial clearance (mm) | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 |
