37mm 12V Small Gear Reduction Motor For Serving Robots

Factory direct sale high quality 37mm 12V Small Gear Reduction Motor For Serving Robots , Chaoya is a leading Gear motor manufacture and supplier in china. 37mm 12V Small Gear Reduction Motor For Serving Robots is highly customizable, with different gear ratios and shaft configurations available to meet specific application requirements. This flexibility makes it a better fit for various robotic applications, enhancing performance and reducing cost.

Send Inquiry

Product Description

High quality 37mm 12V Small Gear Reduction Motor For Serving Robots produced by china factory Chaoya, this motor is well-suited for various robotic applications that require a high level of precision movement, such as serving robots. The gear reduction system in the motor allows for greater speed reduction or increase, higher efficiency, and improved torque output. This makes it optimal for serving robots, where a high level of precision and control is crucial. The 37mm 12V Small Gear Reduction Motor for Serving Robots is highly customizable, with different gear ratios and shaft configurations available to meet specific application requirements. This flexibility makes it a better fit for various robotic applications, enhancing performance and reducing cost. In terms of motor applications, brushed DC motors make good generators,these motors generate electricity when the shaft is turned by an external force. Once turned, they can generate electrical power that can be used to power various devices or stored in batteries for later use.

GearBox  Parameters:

Step  3rd step fourth step fifth step Sixth step Seventh step
Length(mm) 23.7 26.2 28.7 31.2 33.7
Efficience 68% 60% 53% 46% /
Reducer Ratio 13, 18, 23, 30 50, 60, 70, 90, 100 120, 150, 180, 210, 270, 300 350, 405, 420, 540, 630, 810, 1000 /
Rated Turque
Momentary Allowable Turque

Remark:

1.Can be equipped with 5#series brushed motor/36#brushless motor

2.Operation temperature:-40℃~+80℃

3.Output shaft can be customized upon request

Motor Parameters:

Model Voltage(V)  No Load Rotating Speed(rpm)  No-load current(mA) Load torque(gf.cm)  Load Rotating Speed(rpm)  Load Current(A)
RC395 12 5700 100 81 4775 0.5

Motor +GearBox Parameters:

Gear Motor Model Reducer Ratio 13 30 50 100 120 300 350 630 / /
37GB-RC395 No Load Rotating Speed(rpm)  438 190 114 57 48 19 16 9 / /
Rated Torque(kgf.cm) 0.72 1.65 2.43 4.86 5.15 12.88 13.04 23.47 / /
Rated Rotating Speed(rpm) 367 159 96 48 40 16 14 8 / /
